Secure and Govern AI Agents with Microsoft Agent Governance Toolkit: Policies, Approvals, Audit Logs, and Risk Controls

scenarios = [
   {
       "name": "Safe database read",
       "tool": research_db,
       "kwargs": {
           "table": "customers",
           "operation": "select",
           "type": "select",
           "sensitivity": "medium"
       }
   },
   {
       "name": "Blocked destructive database action",
       "tool": research_db,
       "kwargs": {
           "table": "customers",
           "operation": "drop",
           "type": "drop_table",
           "sensitivity": "critical"
       }
   },
   {
       "name": "External correspondence requiring approval",
       "tool": research_email,
       "kwargs": {
           "to": "[email protected]",
           "recipient_domain": "example.com",
           "subject": "Quarterly highlights",
           "body": "Sharing a non-sensitive quarterly summary.",
           "type": "send_email",
           "sensitivity": "medium"
       }
   },
   {
       "name": "External message denied as approval was declined",
       "tool": research_email,
       "kwargs": {
           "to": "[email protected]",
           "recipient_domain": "example.com",
           "subject": "Confidential strategy",
           "body": "This contains private strategic details.",
           "type": "send_email",
           "sensitivity": "critical"
       }
   },
   {
       "name": "Secure sandbox shell task",
       "tool": ops_shell,
       "kwargs": {
           "command": "echo Agent governance is active",
           "type": "shell_exec",
           "sensitivity": "low"
       }
   },
   {
       "name": "Risky shell command prevented",
       "tool": ops_shell,
       "kwargs": {
           "command": "rm -rf /content/something",
           "type": "shell_exec",
           "sensitivity": "critical"
       }
   },
   {
       "name": "Untrusted agent barred from sensitive information",
       "tool": shadow_db,
       "kwargs": {
           "table": "executive_compensation",
           "operation": "select",
           "type": "select",
           "sensitivity": "critical"
       }
   },
   {
       "name": "Monetary transfer needing clearance",
       "tool": finance_transfer,
       "kwargs": {
           "amount": 2500,
           "destination": "vendor-123",
           "type": "transfer_money",
           "sensitivity": "high"
       }
   },
   {
       "name": "Substantial monetary transfer dismissed",
       "tool": finance_transfer,
       "kwargs": {
           "amount": 15000,
           "destination": "vendor-999",
           "type": "transfer_money",
           "sensitivity": "critical"
       }
   },
]
results = []
for scenario in scenarios:
   try:
       response = scenario["tool"](**scenario["kwargs"])
       results.append({
           "scenario": scenario["name"],
           "status": "completed",
           "output": response
       })
   except Exception as error:
       results.append({
           "scenario": scenario["name"],
           "status": "blocked_or_in_review",
           "error": str(error)
       })
audit_dataframe = audit_log.to_dataframe()
columns_to_show = [
   "timestamp",
   "agent_name",
   "tool_name",
   "decision",
   "matched_rule",
   "severity",
   "reason",
   "record_hash"
]
display(audit_dataframe[columns_to_show])
test_cases = [
   {
       "name": "drop_table must be prevented",
       "identity": research_agent,
       "tool_name": "query_database",
       "action": {"type": "drop_table", "sensitivity": "critical", "autonomous": True},
       "expected": "deny"
   },
   {
       "name": "Basic select permitted",
       "identity": research_agent,
       "tool_name": "query_database",
       "action": {"type": "select", "sensitivity": "low", "autonomous": True},
       "expected": "allow"
   },
   {
       "name": "External email should require approval",
       "identity": research_agent,
       "tool_name": "send_email",
       "action": {
           "type": "send_email",
           "recipient_domain": "example.com",
           "sensitivity": "medium",
           "autonomous": True
       },
       "expected": "require_approval"
   },
   {
       "name": "Low trust limited data access",
       "identity": unknown_agent,
       "tool_name": "query_database",
       "action": {"type": "select", "sensitivity": "critical", "autonomous": True},
       "expected": "deny"
   },
   {
       "name": "Terminal command needs isolation",
       "identity": ops_agent,
       "tool_name": "shell_exec",
       "action": {
           "type": "shell_exec",
           "command": "echo hello",
           "sensitivity": "low",
           "autonomous": True
       },
       "expected": "sandbox"
   },
]
test_outcomes = []
for case in test_cases:
   result = engine.evaluate(
       identity=case["identity"],
       tool_name=case["tool_name"],
       action=case["action"]
   )
   success = result.decision == case["expected"]
   test_outcomes.append({
       "test": case["name"],
       "expected": case["expected"],
       "actual": result.decision,
       "passed": success,
       "matched_rule": result.matched_rule
   })
results_table = pd.DataFrame(test_outcomes)
display(results_table)
engine.activate_kill_switch()
try:
   research_db(
       table="customers",
       operation="select",
       type="select",
       sensitivity="low"
   )
except Exception as error:
   pass
engine.deactivate_kill_switch()
audit_dataframe = audit_log.to_dataframe()
summary_stats = (
   audit_dataframe
   .groupby(["decision", "severity"], dropna=False)
   .size()
   .reset_index(name="total")
   .sort_values("total", ascending=False)
)
display(summary_stats)
agent_analysis = (
   audit_dataframe
   .groupby(["agent_name", "decision"])
   .size()
   .reset_index(name="total")
   .sort_values(["agent_name", "total"], ascending=[True, False])
)
display(agent_analysis)
decision_breakdown = audit_dataframe["decision"].value_counts()
plt.figure(figsize=(8, 5))
decision_breakdown.plot(kind="bar")
plt.title("Governance Verdicts throughout All Agent Tasks")
plt.xlabel("Decision Type")
plt.ylabel("Frequency")
plt.xticks(rotation=30)
plt.tight_layout()
plt.show()
severity_split = audit_dataframe["severity"].fillna("none").value_counts()
plt.figure(figsize=(8, 5))
severity_split.plot(kind="bar")
plt.title("Governance Occurrences by Urgency")
plt.xlabel("Severity Level")
plt.ylabel("Occurrence")
plt.xticks(rotation=30)
plt.tight_layout()
plt.show()
G = nx.DiGraph()
for _, entry in audit_dataframe.iterrows():
   agent_label = f"Agent: {entry['agent_name']}"
   tool_label = f"Tool: {entry['tool_name']}"
   decision_label = f"Decision: {entry['decision']}"
   rule_label = f"Rule: {entry['matched_rule']}" if pd.notna(entry["matched_rule"]) else "No matched rule"
   G.add_node(agent_label, node_type="agent")
   G.add_node(tool_label, node_type="tool")
   G.add_node(decision_label, node_type="decision")
   G.add_node(rule_label, node_type="rule")
   G.add_edge(agent_label, tool_label, relation="calls")
   G.add_edge(tool_label, decision_label, relation="produces")
   G.add_edge(decision_label, rule_label, relation="matched")
plt.figure(figsize=(14, 9))
coord_map = nx.spring_layout(G, seed=42, k=0.8)
nx.draw_networkx_nodes(G, coord_map, node_size=1800)
nx.draw_networkx_edges(G, coord_map, arrows=True, arrowstyle="->", arrowsize=15)
nx.draw_networkx_labels(G, coord_map, font_size=8)
plt.title("Agent Governance Mapping: Participants, Tools, Verdicts, and Policy Rules")
plt.axis("off")
plt.tight_layout()
plt.show()
SAVE_PATH = "/content/agt_tutorial_outputs"
os.makedirs(SAVE_PATH, exist_ok=True)
audit_json_file = os.path.join(SAVE_PATH, "tamper_evident_audit_log.json")
audit_csv_file = os.path.join(SAVE_PATH, "governance_audit_log.csv")
policy_backup_file = os.path.join(SAVE_PATH, "advanced_agent_policy.yaml")
test_file = os.path.join(SAVE_PATH, "policy_test_results.csv")
with open(audit_json_file, "w") as json_out:
   json.dump([asdict(record) for record in audit_log.records], json_out, indent=2, default=str)
audit_dataframe.to_csv(audit_csv_file, index=False)
results_table.to_csv(test_file, index=False)
shutil.copy(POLICY_PATH, policy_backup_file)
