## End-to-End GeoAI Workflow for Building Footprint Extraction from NAIP Imagery
This article presents a complete geospatial deep learning pipeline for extracting building footprints from high-resolution NAIP aerial imagery. It covers environment setup, data acquisition, inspection, training, inference, post-processing, evaluation, and extension to real-world scenarios using open data sources.
### Environment Setup and Data Acquisition
The workflow begins by configuring the environment. Required packages such as `geoai`, `segmentation-models-pytorch`, and `buildingregulariser` are installed, and GPU availability is verified. Core parameters—tile size, stride, architecture, optimizer settings, and experiment flags—are defined in a central configuration object. The pipeline downloads NAIP RGB imagery and corresponding vector labels for training and testing from a public host.
### Data Inspection and Visualization
Raster and vector datasets are inspected for coordinate reference systems, dimensions, and per-band statistics. Building footprints are visualized over the aerial imagery, and an interactive map is generated for spatial exploration. Training scenes are divided into overlapping georeferenced image chips and corresponding segmentation masks to prepare balanced and geolocated patches for model training.
### Model Training and Diagnostics
A U-Net semantic segmentation model with a ResNet-34 encoder is trained using the prepared chips and masks. Training includes validation splits, early stopping, checkpointing, and learning curve monitoring. After training, loss and IoU metrics are plotted, and the best epoch is selected based on validation performance. The article explains how to diagnose overfitting and underfitting from these curves.
### Prediction, Post-Processing, and Evaluation
Sliding-window inference is applied to an unseen test scene, producing prediction masks and probability rasters. Small noisy regions are removed, and predicted masks are converted into vector polygons. These vectors are further processed through orthogonalization and regularization to produce clean, regularized building footprints with geometric attributes such as area, perimeter, and orientation. Pixel-wise evaluation metrics, including IoU and F1, are computed against rasterized ground truth to quantify segmentation accuracy.
### Zero-Shot and Pretrained Alternatives
The pipeline also demonstrates zero-shot building segmentation using Grounding DINO and SAM with text prompts like “building,” “house,” and “rooftop,” enabling segmentation without model retraining. In addition, a pretrained Mask R-CNN model is used to extract individual building instances, and the results are compared with those from the U-Net approach to highlight differences between semantic segmentation and instance segmentation.
### Real-World Extension
Optionally, the same workflow can be applied to real-world areas by downloading NAIP imagery from the Microsoft Planetary Computer and building labels from Overture Maps. STAC searches help identify suitable scenes, and the prepared tiles can be fed into the training pipeline for localized footprint extraction.
### Results Packaging
Finally, all generated assets—including prediction masks, probability rasters, training curves, model checkpoints, and GeoJSON footprints—are packaged into a single archive for sharing, deployment, or further analysis.
—
## FAQ
**What is GeoAI, and why is it used here?**
GeoAI combines geospatial data science with artificial intelligence to extract meaningful insights from spatial data. In this workflow, GeoAI utilities handle downloading, tiling, visualization, model training, inference, and post-processing of geospatial data.
**What hardware is recommended?**
A GPU (such as an NVIDIA T4) is recommended for faster training. The code checks for CUDA availability and will run on CPU if a GPU is not present, albeit more slowly.
**Can I use this pipeline with other datasets?**
Yes. The pipeline is designed to work with NAIP imagery and vector labels, but it can be adapted to other high-resolution aerial images and building datasets by updating the raster and vector sources and adjusting parameters.
**What are the key differences between U-Net and Mask R-CNN here?**
U-Net performs semantic segmentation, producing dense pixel-level masks that naturally merge adjacent roof areas. Mask R-CNN provides instance segmentation, returning individual building polygons that often split merged roofs into separate objects. The choice depends on whether you need dense masks or discrete instances.
**What is zero-shot segmentation?**
Zero-shot segmentation uses foundation models like Grounding DINO and SAM to detect and segment objects based on text prompts without training a custom model. In this article, prompts such as “building” are used to segment buildings directly.
**How are model performance metrics computed?**
IoU (Intersection over Union) and F1 scores are computed by comparing predicted masks to ground-truth raster labels on a per-pixel basis. IoU measures overlap quality, while F1 balances precision and recall.
**What output formats are generated?**
The pipeline produces GeoTIFF masks and probability rasters, GeoJSON vector footprints, training curves, evaluation plots, and a compressed ZIP archive containing key results.
—
## Conclusion
This article demonstrates an end-to-end geospatial deep learning pipeline that transforms raw NAIP aerial imagery into structured, analysis-ready building footprints. The workflow includes data inspection, chip generation, U-Net training with detailed diagnostics, sliding-window inference, and post-processing to yield orthogonalized vector footprints. It also explores alternative approaches—zero-shot segmentation with Grounding DINO + SAM and pretrained Mask R-CNN—to highlight trade-offs between custom-trained models and prompt-based methods. By packaging predictions, probabilities, evaluations, and geometries into a reusable format, the pipeline provides a strong foundation for large-scale GeoAI tasks such as infrastructure mapping, change detection, and land-cover analysis.
—
