How a SciPy ODE Solver Derailed My Bayesian Inference — A Cosmologist’s Journey to Discovering Diffrax

from scipy.integrate import solve_ivp
import numpy as np

C_KMS = 299792.458    # speed of light [km/s]

def rhs(z, chi, Om, H0):
    return C_KMS / (H0 * np.sqrt(Om*(1+z)**3 + (1-Om)))

def forward_scipy(Om, H0, z_obs):
    sol = solve_ivp(rhs, t_span=(0, z_obs[-1]),
                    y0=[0.0], t_eval=z_obs,
                    args=(Om, H0), method="RK45",
                    rtol=1e-8, atol=1e-10)
    chi = sol.y[0]
    return 5 * np.log10((1 + z_obs) * chi * 1e5)   # distance modulus

from scipy.integrate import solve_ivp
import numpy as np

C_KMS = 299792.458    # speed of light [km/s]

def rhs(z, chi, Om, H0):
    return C_KMS / (H0 * np.sqrt(Om*(1+z)**3 + (1-Om)))

def forward_scipy(Om, H0, z_obs):
    sol = solve_ivp(rhs, t_span=(0, z_obs[-1]),
                    y0=[0.0], t_eval=z_obs,
                    args=(Om, H0), method="RK45",
                    rtol=1e-8, atol=1e-10)
    chi = sol.y[0]
    return 5 * np.log10((1 + z_obs) * chi * 1e5)   # distance modulus

import jax, jax.numpy as jnp
import diffrax as dfx

# Non-negotiable: enable 64-bit (more on this below)
jax.config.update("jax_enable_x64", True)

def H_jax(z, Om, H0):
    return H0 * jnp.sqrt(Om*(1+z)**3 + (1-Om))

@jax.jit                             # compile once, call fast forever
def forward_diffrax(theta, z_obs):
    Om, H0 = theta[0], theta[1]
    sol = dfx.diffeqsolve(
        dfx.ODETerm(lambda z, chi, a: C_KMS / H_jax(z, a[0], a[1])),
        dfx.Tsit5(),
        t0=0.0, t1=float(z_obs[-1]),  # initial and final value
        dt0=1e-3,                     # initial step-size
        y0=jnp.array(0.0),            # initial condition
        args=(Om, H0),
        saveat=dfx.SaveAt(ts=z_obs),
        stepsize_controller=dfx.PIDController(rtol=1e-8, atol=1e-10),
        max_steps=10_000,
    )
    chi = sol.ys
    return 5 * jnp.log10((1 + z_obs) * chi * 1e5)

Here is the paraphrased version of the article:

59 μs per call. That’s 6.8× faster.

When I first saw this figure, I paused for a moment to take it in. Let me be upfront about where the speed improvement actually comes from — it’s not some kind of trick.

With solve_ivp, Python re-enters the C/Cython backend on every single call. Fresh memory gets allocated each time. The adaptive while-loop passes through the Python interpreter repeatedly, checking: “Is the local error too high? If so, reject the step; otherwise, increase the step size; repeat.” For a solve that takes 12 steps, that means 12 rounds of Python dispatch, 12 separate memory allocations, and 12 error-estimate calculations — all bottlenecked by the interpreter.

With diffrax, the first @jax.jit call traces the entire computation — including the adaptive while-loop, which gets compiled down to a lax.while_loop and handed off to XLA to produce a single machine-code kernel. Every call after that runs the kernel directly. No Python overhead, no repeated allocations, no dispatch cost.

Across 100,000 likelihood evaluations, 404 μs versus 59 μs adds up to 40.4 seconds compared to 5.9 seconds. And this gap only widens as the model grows more complex.

Surprise 2: gradients come at no extra cost

This was the part that didn’t just change my workflow — it fundamentally shifted how I approach inference. Using scipy, computing a single gradient of the log-likelihood with respect to two parameters (Ωₘ, H₀) requires 4 forward solves (via central finite differences). As you scale up, the cost climbs quickly: 10 parameters demand 20 forward solves, 50 parameters demand 100. The expense grows linearly with the number of parameters.

$frac{partialmathcal{F}}{partialOmega_m} approx frac{mathcal{F}(Omega_m+h,H_0) – mathcal{F}(Omega_m-h,H_0)}{2h}, qquad frac{partialmathcal{F}}{partial H_0} approx frac{mathcal{F}(Omega_m,H_0+h) – mathcal{F}(Omega_m,H_0-h)}{2h}$

With diffrax, all I need to write is:

def loss(theta):
    mu_pred = forward_diffrax(theta, z_obs)
    return 0.5 * jnp.sum(((mu_pred - mu_obs) / sigma_mu)**2)

grad_fn = jax.jit(jax.grad(loss))      # that's the only change needed
g = grad_fn(jnp.array([0.3, 70.0]))    # exact gradient

Behind the scenes, JAX’s reverse-mode automatic differentiation integrates the adjoint equations [2] backward through the ODE solve — but I never have to derive or code those equations myself. The result is an exact gradient at a cost roughly equal to a single forward pass, regardless of how many parameters there are.

How to pick the right solver

Choosing an appropriate solver requires a bit of thought. I defaulted to Tsit5 for nearly everything, and it handled about 95% of my use cases without any issues. Here’s the full decision process:

• Non-stiff ODE (most cosmological problems) → dfx.Tsit5() ← start here
• Very tight tolerances (< 10⁻⁹) → dfx.Dopri8()
• Stiff ODE (many steps, solver feels sluggish) → dfx.Kvaerno5()
• Stiff + non-stiff terms (IMEX) → dfx.KenCarp4()
• SDE → dfx.EulerHeun() or dfx.SPaRK()

A quick test for stiffness: print sol.stats["num_steps"]. If the step count is 10–100× higher than expected, your problem is stiff and you’ll need an implicit solver.

The payoff: end-to-end cosmological inference

Now let me walk through the full inference comparison. Both pipelines start from the same poor initial guess (Ωₘ, H₀) = (0.10, 60), far from the true values (0.30, 70), and run for 350 gradient steps.

• Scipy pipeline: gradients via central finite differences, plain gradient descent, fixed learning rate.
• Diffrax pipeline: gradients via autodiff, Adam optimizer with a cosine-decay learning-rate schedule.

import optax   # optimizers for JAX

# Rescale parameters so Adam treats them on equal footing
# Om ~ 0.3,  h = H0/100 ~ 0.7  -- both O(1) now
def loss_scaled(theta_s):
    theta = jnp.array([theta_s[0], 100.0 * theta_s[1]])
    return loss(theta)

grad_scaled = jax.jit(jax.grad(loss_scaled))

schedule
method = opt.init(theta)

for step in range(350):
    g = grad_fn(theta)
    updates, state = opt.update(g, state)
    theta = optax.apply_updates(theta, updates)
    if (step + 1) % 50 == 0:
        print(f"Step {step+1}: Om={theta[0]:.3f}  H0={100*theta[1]:.2f}")

While the diffrax pipeline recovers physically meaningful parameters, the scipy pipeline fails to adjust both parameters at once — a classic example of gradient descent struggling with poorly scaled problems. Adam resolves this automatically through its per-parameter adaptive learning rates, but Adam can only do this because autodiff supplies it with exact gradients.

Three mistakes I made (so you can avoid them)

Pitfall 1: neglecting 64-bit precision. JAX uses 32-bit floats by default. When you tighten tolerances (rtol < 10⁻⁷), this can produce unexpected behaviour: on my ODE the solver takes 69 steps in 32-bit mode versus just 12 in 64-bit. Push the tolerances even tighter and it may fail entirely. The remedy is straightforward — activate 64-bit mode before doing anything else:

jax.config.update("jax_enable_x64", True)   # must be set first

Pitfall 2: timing without a warm-up run. The first invocation of any @jax.jit-decorated function carries a one-time compilation overhead of roughly 90–100 ms. If you include that in your benchmarks, diffrax will appear slower than scipy for the wrong reason. The solution is to run once for warm-up and discard that initial result:

_ = forward_diffrax(theta, z_obs).block_until_ready()  # trigger compilation
# NOW time it -- this reflects the true speed

Also: JAX dispatches work asynchronously. Always use .block_until_ready() inside timing loops, or you’ll measure only the time to queue the computation rather than complete it.

Pitfall 3: the argument-order trap. scipy.odeint expects f(y, t) (state first, time second). Nearly everything else (solve_ivp, diffrax) expects f(t, y). If you migrate old odeint code to diffrax without swapping the arguments, you end up solving a different ODE — and you typically won’t see an error. You’ll simply get the wrong result.

Should you switch?

The honest take: if you’re solving a single ODE and don’t need gradients, solve_ivp works just fine — there’s no reason to learn a new API. But if you’re doing inference (repeated likelihood evaluations, parameter gradients, or batched solves), the switch is well worth the effort.

The migration itself is minimal. The forward model requires roughly six changed lines. The gradient appears with just one additional line. The rest of the inference code remains unchanged.

One important clarification: diffrax is not “ML-based” in the sense of employing a neural network. It uses the same classical Runge–Kutta mathematics, implemented in JAX. The “ML acceleration” comes from JIT compilation and autodiff — both infrastructure tools borrowed from the ML world and applied to a classical numerical solver. The only truly ML-based approach would be a neural surrogate that learns θ → μ(z) from training data — a separate and more advanced topic.

The complete working code

Everything above condensed into a single self-contained script (pip install jax diffrax optax):

"""
flat_lcdm_inference.py
Infer (Omega_m, H0) from 30 mock supernovae using diffrax + Adam.
pip install jax diffrax optax
"""
import jax, jax.numpy as jnp, numpy as np
import diffrax as dfx, optax
from scipy.integrate import solve_ivp  # only for generating mock data

jax.config.update("jax_enable_x64", True)

# -- Constants and data -----------------------------------------------
C_KMS = 299792.458
z_obs = jnp.linspace(0.05, 1.5, 30)
SIGMA = 0.10

# Mock data at truth (Om=0.30, H0=70)
def chi_np(Om, H0):
    sol = solve_ivp(lambda z, y: C_KMS/(H0*np.sqrt(Om*(1+z)**3+(1-Om))),
                    (0, 1.5), [0.], t_eval=np.array(z_obs), rtol=1e-10)
    return sol.y[0]

mu_true = 5*np.log10((1+np.array(z_obs))*chi_np(0.3, 70.)*1e5)
mu_obs  = jnp.array(mu_true + 0.10*np.random.default_rng(42).standard_normal(30))

# -- diffrax forward model --------------------------------------------
@jax.jit
def forward(theta):
    Om, H0 = theta[0], theta[1]
    sol = dfx.diffeqsolve(
        dfx.ODETerm(lambda z, chi, a:
            C_KMS/(a[1]*jnp.sqrt(a[0]*(1+z)**3+(1-a[0])))),
        dfx.Tsit5(),
        t0=0., t1=1.5, dt0=1e-3, y0=jnp.array(0.),
        args=(Om, H0),
        saveat=dfx.SaveAt(ts=z_obs),
        stepsize_controller=dfx.PIDController(rtol=1e-8, atol=1e-10),
        max_steps=10_000,
    ).ys
    return 5*jnp.log10((1+z_obs)*sol*1e5)

# -- Loss and gradient ------------------------------------------------
def loss(th_s):   # optimise in scaled coords (Om, h=H0/100)
    mu = forward(jnp.array([th_s[0], 100.*th_s[1]]))
    return 0.5*jnp.sum(((mu - mu_obs)/SIGMA)**2)

grad_fn = jax.jit(jax.grad(loss))

# Warm up the JIT compiler
theta_init = jnp.array([0.10, 0.60])
_ = forward(jnp.array([0.3, 0.7])).block_until_ready()
_ = grad_fn(theta_init).block_until_ready()

# -- Adam optimiser with cosine LR schedule ---------------------------
sched = optax.cosine_decay_schedule(init_value=0.05, decay_steps=350, alpha=0.04)
opt   = optax.adam(sched)
theta = theta_init
state = opt.init(theta)

for step in range(350):
    g = grad_fn(theta)
    updates, state = opt.update(g, state)
    theta = optax.apply_updates(theta, updates)
    if (step + 1) % 50 == 0:
        print(f"Step {step+1}: Om={theta[0]:.3f}  H0={100*theta[1]:.2f}")

theta = opt.init(theta)

print(f"{'Step':>5}  {'Om':>7}  {'H0':>7}  {'Loss':>8}")
for step in range(350):
    g = grad_fn(theta)
    upd, state = opt.update(g, state)
    theta = optax.apply_updates(theta, upd)
    if (step + 1) % 70 == 0 or step == 0:
        L = float(loss(theta))
        print(f"{step+1:5d}  {float(theta[0]):7.4f}  {100*float(theta[1]):7.3f}  {L:8.2f}")

Om_fit, H0_fit = float(theta[0]), 100*float(theta[1])
print(f"nFinal:  Om = {Om_fit:.3f}  H0 = {H0_fit:.2f}")
print(f"Truth:  Om = 0.300  H0 = 70.00")

Key Results Summary

The incorrect scipy outcome isn’t due to solver failure—it stems from basic gradient descent with finite-difference gradients struggling with the 200× scale difference between Ωₘ and H₀.

Closing Reflection

Migrating my forward model to diffrax left the physics and inference approach untouched. What it did change was whether performing that inference was even practical. A nested-sampling run that was trending toward a massive forward-model time budget shrank to under a minute. Gradients that previously demanded 20 additional solves per step became virtually cost-free.

The learning curve took roughly one afternoon. Most of the troubleshooting involved the 64-bit precision caveat and initial JIT warmup confusion. The benefits have been tangible and instant.

If you’re a physicist relying on scipy for repeated likelihood evaluations and haven’t explored diffrax yet, I hope this gives you a compelling reason to start.

A note on reproducibility: the precise timings you observe will vary on your machine and even between runs on the same system. On my Mac (MacBook Air M3 Base Model), the diffrax forward call ranged from 55 μs to 62 μs across sessions, while scipy ranged from 400 μs to 407 μs. This variation is expected—CPU thermal conditions, OS scheduling, and memory cache states all shift absolute numbers by roughly 10–15%. What remains consistent is the ratio: diffrax is reliably 7–8× faster than scipy on this problem. Focus on the ratio, not the absolute time, as the key takeaway.

The Python code that produced every figure in this article is available at: github.com/Samit1424/ODE_solver_comparison

Note: Excluding the featured image, which was generated using an AI tool, all illustrations are the author’s original work.

References

[1] P. Kidger, On Neural Differential Equations, DPhil thesis, University of Oxford, 2021. docs.kidger.site/diffrax/

[2] R. T. Q. Chen, Y. Rubanova, J. Bettencourt, D. Duvenaud, Neural Ordinary Differential Equations, NeurIPS 2018.
